RP2350pc

RP2350pc - Open Source Hardware Board
RP2350pc - Open Source Hardware Board RP2350pc - Open Source Hardware Board RP2350pc - Open Source Hardware Board
RP2350B all in one computer with 16MB Flash, 8MB PSRAM, DVI / HDMI display 4 USB hosts Stereo Audio and UEXT connector
Price24.95 EUR
In Stock
RP2350pc is all in one computer with 16MB SPI Flash, 8MB PSRAM, 4x USB2.0 hosts, Stereo Audio codec and Amplifier, DVI/HDMI output, Lipo battery charger, UEXT connector, USB-C power supply connector.
With the Reload emulator it can emulate Apple ][, Apple ][e, Oric-Atmos, Pravetz, Puldin 8-bit old computers.
You can play all thousands of Total Replay games on it.
The USB host support USB Flash drives, USB Game pads (USB-GAMEPAD emlates Apple Joystick), USB Keyboard.

FEATURES

  • RP2350B Dual Arm Cortex-M33 or dual Hazard3 RISC-V processors @ 150MHz
  • 520 KB on-chip SRAM
  • 16MB SPI Flash
  • 8MB of PSRAM
  • DVI/HDMI output
  • x4 USB hosts
  • Audio Codec with Stereo Audio Amplifier
  • PWM Stereo Audio generation
  • Audio 3.5mm Line-in
  • Audio 3.5mm headphones connector
  • two JST2.0 connectors for left and right speaker
  • USB-C connector for power supply
  • USB-C connector for programming
  • two UEXT connectors
  • Power switch
  • RP2350B reset and programming bootloader button
  • Four mounting holes 3.3mm diameter
  • Lipo battery charger and JST 2.0 connector
  • microSD card
  • Dimensions (85 x 65)mm

DOCUMENTS

  • RP2350pc user manual
  • RP2350pc EU declaration of conformity
  • RP2350pc UKCA declaration of conformity
